SPRAYERS



The sprayer is a machine for the chemical processing of several cultivations.

The “atomization” developed by the current of air grants a correct penetration of the jet inside the leaf, even when it is particularly thick, so that even the most internal leaves be reached and fully covered by the atmosphere with the plant protection product.

The machine consists of:

  • Tank with a capacity of 500-200 litres
  • Generally diagram pump with the following features:
    • Capacity 60 l/m – 160 l/m
    • Pressare 50 Kg/cm²
  • Fan unit with fan having a diameter of 400-1000 mm. the fan performances depend on various factors such as propeller size, shape of blades, number of r.p.m.

The average charachteristics are: Rotation speed: 1500 — 2800 g/min.

Air capacity: 20.000 – 80.000 m³/h

Output air speed: 35 — 40 m/sec.

  • Multiplier unit Usually the fan is driven by a two-speed multiplier unit with position in neutral that takes its motion from the tractor by the P.T.O. drive shaft and grants 1500 – 2800 rev./min. The two speed supplied by the multiplier unit mainly have two purposes:
    • To cover an area depending on the type of cultivation to be worked
    • To enable to submit the involved area to a more or less powerful processing according with the blossoming progress.

Gearboxes for this kind of machine:

- D.7A (9.603.373.00 – 9.603.012.00)

- D.27A

- D.21°



The indicative possible ratios are: 1:2,5 — 1:3 — 1:3,5 — 1:4 — 1:4,5 — 1:5 with powers from 30 up to 60 HP.

Herewith there is table of the most significant technical details of the machine.

There is disposes also of the availability of centrifugal clutches for the atomizer, besides the multiplier unit.

They are safety units granting the protection of the transmission parts as well as a smoother start and eliminating the fan inertia on the multiplier unit when the machine stops.

They consist of a mid part fitted on the multiplier output shaft with two jaws held by two springs and by an outer part fastened to the fan propeller.

When the machine starts the multiplier unit shaft turns without compelling the fan: just when the number of revolutions is about 700-900, the centrifugal force on the jaws exceeds the springs’ resistance and by the jaws expand and with the lining they touch the outer side of the clutch, after this the fan starts to rotate.

The opposite occurs when the machine stops, this means that when the tractor stops, the multiplier output shaft stops, so there is non centrifugal force on the jaws that withdraw because of the springs and leave the fan in neutral with its free stroke.







Tank capacity

(Litri)

Pump delivery (L/min)

Pump pressure (kg/cmq)

Fan diameter (Cm)

N° turns

(g/min.)



Air flow (Mc/h)



Power

tractor

(CV)

500

60

50

60

2500

30000

20

600

80

40

60

2800

30000

22

600

80

50

64

2000

42000

25

700

60

50

60

1800

30000

25

800

100

40

70

2500

40000

25

600

85

50

70

2500

35000

30

800

120

50

80

2400

60000

35

1000

100

50

82

2000

42000

35

1000

120

50

78

2450

77000

40

1000

120

40

81

2500

54000

40

1200

120

50

82

2200

48000

40

1200

120

50

85

2400

80000

45

1500

140

50

82

2200

48000

50

1500

130

50

85

2400

80000

50

1500

120

40

91

2300

70000

55

1500

120

50

64

3000

30000

60

2000

140

50

90

2200

50000

60

1500

130

50

90

2000

54000

70



The range of P.T.O. drive shafts normally used on this type of machine is

Series: V  Type:  CVJ40  – CVJ60

Ex.: 98610860EN002012 / 98610860EN002012 / 78411110EN002010





- Recommended code list

9.603.373.00 – 9.603.012.00
