PRODUCT details

MANUFACTURER: Motovario S.P.A.

FEATURES:

CBA 052 C i25,03 D25 B7 T71B4
Helical bevel gear: compact CB
Size: A52
Series: ONN
Casing version: U-Universal
Output Shaft Version: C-Hollow shaft
Ratio (i): 25,03

Output Shaft Dim.: D.25
Direction of rotation: Standard

Mounting position: U
ON-Oil plugs: No plugs (Standard)

Supplied complete with synthetic based lubricant, Eni Rotra MP85W-140

Output oil seal: NBR-Nitrile
Output bearings: Ball
Lubrication: Eni Rotra MP85W-140

Paint: Ral 5010 blue

Motor/Motoinverter: Con Motor
Regulations: CE
Motor: Three-phase
Size: 071
Series: Aluminum
Poles: 4
Electrical Execution: Standard
Winding: D/Y (6 Std Term.)
Duty: S1
Voltage: 230/400-230/460 V
Frequency: 50-60 Hz
Power: 0,37 kW
Coooling: Self-ventilated
Mounting: B10
Morsettiera: Pos.1
Dim.Flange: A
Dim.Albero (DE): Foro D.7
Insulation reating: F
Protection Rating: IP55
Ambient Conditions: TROP1 Tropicalized
Terminal Box Cover: Plastic
Cable Glands \ Plugs: Plastic
Fan: Plastic
Fan cover: Standard
Bearing: Ball 2RS1
Oil Seal: NBR-Nitrile
Paint: Not paited
