SAWS

CIRCULAR SAWS:
It is a machine for wood cutting, made out a disc driven, with a belt, by an angle transmission taking its motion from the tractor through a cardan shaft. Gearboxes for this kind of machine: L.5 A L.25 A (9.124.004.30 – 9.124.021.02 – 9.124.104.10) T.19 G (9.259.232.00) L.27 A (9.267.021.00 – 9.267.023.00) The range of P.T.O. driveshaft normally used on this type of machine is: Series: T Type: 10 / 20 / 40 Safety device: Suggested: Bolt torque limiter (B) Ex.: 07.435.039.10 - Recommended code list 9.124.004.30 – 9.124.021.02 – 9.124.104.10 9.259.232.00 9.267.021.00 – 9.267.023.00 BELT SAWS:
It is a machine for wood cutting made out of two pulleys, driving a notche belt that is the working unit. Usually motion reaches the driving pulley by means of belts taking the motion from an angle gearbox driven by the tractor P.T.O. through a cardan shaft. Gearboxes for this kind of machine: T.281 G (9.281.009.00) T.19 G (9.259.232.00) T.27 A (9.267.021.00 – 9.267.023.00) The range of P.T.O. drive shafts normally used on this type of machine is: Series: T Type: 10 / 20 / 40 Safety device: Suggested: Bolt torque limiter (B) Ex.: 07.435.039.10 - Recommended code list 9.281.009.00 9.259.232.00 9.267.021.00 – 9.267.023.00
