PRODUCT details

9.603.012.00

GEARBOX 3.8 M-58 R-16 .6 A-4A

€ 1.272,67
LIMITED AVAILABILITY
Shipment Costs
  • Trasporto a mezzo corriere Bartolini BRT 0,00 €
Product details

MANUFACTURER: COMER INDUSTRIES S.P.A.

Model: A-4A

Technical features:

Reduction gear unit
Input power rate: 23Cv-16.6Kw (540RPM)

Speed increasing unit
Input power rate: 79Cv-58Kw (540RPM)

Ratio: 3,8

Outputs: 1

Rotation
The rotation is defined as either clocwise or counter-clockwise by looking "into" the components in motion ( shaft, pulley, or sprocket), with the gearbox behind the component


Shafts Rotation: Download data sheet to check the possible available rotation.

Material: Cast iron

Dry weight: Kg 39

Supplied without lubricant

• Different shafts rotation available (please ask our TECHNICAL DEPARTMENT)

List of combined products
Availability
LIMITED AVAILABILITY
0.603.2000.02

SHAFT

€ 189,71
Availability
LIMITED AVAILABILITY
0.603.5104.01

CROWN WHEEL

€ 446,18
Availability
LIMITED AVAILABILITY
0.603.6103.02

PINION

€ 493,79
Availability
AVAILABLE
8.0.1.00049

BALL BEARING 6307

€ 10,23
